Tarahan Fully Hydraulic Curb Stone Machine – M.CS Series
The fully hydraulic curb stone machine is a mobile, hydraulic machine with an elegant design and easy operation. Equipped with a pressing system and high-power vibrators, it is suitable for producing high-quality curb stones in large capacities.
Specifications of Tarahan M.CS Curb Stone Machine:
- Equipped with a three-phase electrical panel for controlling the automatic curb stone machine and protecting the electric motors.
- The automatic curb stone machine is fed from the hopper via a loader or a winch system.
- The pressing system of the automatic curb stone machine operates in both hammer and press modes.
- Capable of producing curb stones ranging from 30 cm to 100 cm in length.
- Actual cycle time of the machine: 2 minutes.
- Hopper capacity: 1 cubic meter.
Optional Systems Available for Installation on the Machine:
1. Smart PLC System for Full Automation:
This system allows full automation, eliminating the need for an operator.
Advantages of the PLC System:
- Reduces machine wear and tear.
- Enables easy and automatic troubleshooting.
- Minimizes labor costs.
- Controls and adjusts production settings as desired.
- Easy operation via a touchscreen monitor.
2. Winch or Hoist System:
In locations where a loader or tractor is unavailable for feeding the hopper, a winch or hoist system can be installed, reducing costs and simplifying operations.
Model Specifications:
| Model | Name | Production Capacity per Cycle | Curb Stone Size (cm) | Height Range (cm) |
|---|---|---|---|---|
| M.CS | Single-row curb stone machine | 6 pieces per cycle | 30 × 50 cm | 30 to 50 cm |
